Viking Electronics 40TB-IP VoIP Ceiling Speaker with Talkback

The Viking model 40TB-IP Talk-Back Ceiling / Wall Speaker enables two-way conversations via SIP and also allows for standard paging and background music via multicast. The Talk-Back Speaker easily connects with a single CAT5/6 cable from your PoE switch. Its shallow depth allows the speaker to be conveniently mounted in a standard 2″ x 4″ stud wall or ceiling.

An auxiliary switch input allows a hard wired wall button to initiate a SIP call. Alternately, an optional wireless remote call button can be used (Viking model BTR-3, sold separately). A momentary button press will initiate a standard call, and holding the button for 3 or more seconds will initiate an emergency call. The remote can also be used to adjust the speaker volume. The LED on the 40TB-IP can be programmed to blink when there is call activity.

The integrated microphone enables talk-back and also monitors room noise to automatically increase speaker volume when necessary. Line-level audio output connections are provided for connecting to an external amplifier. A built-in 6 Watt class D amplifier with speaker output connections is also provided to directly drive additional analog 8 Ohm speakers.

A programmable relay output is provided for activating door locks, strobe lights, external amplifiers, etc.

Viking Electronics 40TB-IP Features

PoE powered (class 3, less than 13 Watts)
Use with an optional BTR-3 wireless remote to activate calls or adjust speaker volume
Paging prioritization
Plays audio from multicast
SIP endpoint or multicast group member
Supports up to 10 multicast paging groups
Add an optional SL-2 blue, green, red or amber strobe light (see DOD 242)
Blue call status LED indicator
SIP compliant (see product manual for list of compatible IP-PBX phone systems)
Automatic Noise Canceling (ANC) feature for operation in noisy environments
Viking’s proprietary VOX switching eliminates the need for “Push to Talk” mode
Selectable auto-answer feature for monitoring
Autoprovisioning via Viking programming software
Built-in high efficiency 6 Watt class D amplifier
Relay for activating door locks, strobe lights, external amplifiers, etc.
SIP / Multicast: SIP page, SIP page and zoned multicast stream, zoned multicast receive
Support for access code to prevent unwanted SIP calls
Line-level audio output for connecting to an external amplifier
Hangs up on: busy signal, time-out, or touch tone command
Network remote speaker volume control
Can drive additional external analog speakers for greater coverage
Mounting: Blind mounts into 9.5″ hole, clearance requirement of 3.45″ (87.3mm) above 0.5″ gypsum board ceiling
Heavy duty back box protects speaker and circuitry against plenum dust
Automatic Gain Control (AGC) to automatically increase ring volume to compensate for ambient noise
Diagnostics (for testing mic, speaker & relay)
