Description
The Bogen V100 is a 100-watt Power Vector modular amplifier designed for scalable PA installations. Eight input module bays accommodate up to 8 input modules or 2 signal-processing output modules, giving system designers the flexibility to tailor inputs and priority routing to any application.
Key Features
- 8 Module Input Bays - Accepts up to 8 input modules or 2 signal-processing output modules for a fully customized input configuration
- 4 Priority Levels - Four independent priority levels between modules allow automatic source overrides for paging and emergency announcements
- Universal Output - Drives 4-ohm, 8-ohm, 25V, and 70V speaker systems
- Per-Module Controls - Independent volume control, signal indicator, and clip LED per input module
- 11-Segment Output Meter - Visual LED bar-graph meter for real-time output level monitoring
- Rack-Mount Ready - Compatible with optional RPK87 rack mount kit
Technical Specifications
- Power Output: 100 watts
- Module Bays: 8 input, up to 2 signal-processing output
- Output Impedances: 4-ohm, 8-ohm, 25V, 70V
- Priority Levels: 4
