Patton SmartLink M-ATA Analog Telephone Adapter - Open Box

The SmartLink Micro Analog Telephone Adapter provides connectivity for analog phones to a home, home office or corporate LAN. Connecting to any analog phone or PBX, the SmartLink product is ay cost effective solution for small offices and telecommuters to access Internet-based telephone services and corporate intranet systems across established LAN and Internet connections like xDSL and cable modems.

The M-ATA provides one Ethernet (RJ-45) port and one FXS (RJ-11) analog phone port for quick and easy interconnection to the local LAN. LEDs show at-a-glance the status of the system, LAN, WAN, and phone ports.

A full suite of IP features (DHCP, NAT/PAT) are available to maximize universal connectivity. VLAN tagging and prioritization enables voice traffic to be handled before data traffic insuring higher quality voice calls. Support for PPPoE tunneling simplifies extending corporate intranet services to telecommuters.

The user friendly web interface offers two levels of configuration; level one covers basic subscriber specific parameters, level two offers advanced settings for the transport network. Configuration and firmware can be downloaded from a centralized TFTP or HTTP server.

The M-ATA is SIP standard compliant. Analog phones attached to the SmartLink can use advanced calling features such as call forwarding, caller ID, 3-way calling, call holding, call retrieval and call transfer.

Applications
Patton's Micro Analog Telephone Adapter provides seamless access to Internet telephony and data services. The M-ATA connects to any broadband access provider via a cable or xDSL modem.

Specifications

Voice Connectivity	2-wire Loopstart, RJ-11/12 Short haul loop 1.1 km @3REN Caller-ID Type-1/2 FSK and ITU V.23/Bell 202 generation
Connectivity	1 10/100Base-TX Full Duplex/Autosensing Ethernet RJ-45
Voice Processing (signalling dependent)	SIP Voice CODECS (G.711 A-Law/-Law (64 kbps); G.726 (ADPCM 40, 32, 24, 16 kbps); G.723.1 (5.3 or 6.3 kbps); G.729ab (8 kbps)) G.168 echo cancellation 2 parallel voice connections DTMF detection and generation Carrier tone detection and generation Silence suppression and comfort noise Configurable dejitter buffer DTMF in-band & out-of-band Configurable transmit packet length RTP/RTCP (RFC 1889) STUN
Voice Services/Features	Anonymous CallerID block Call blocking Call forward - on busy Call forward - selective Call forward - unconditional Call hold/retrieve Call return Call transfer - blind Call transfer - with consultation Call waiting/retrieval Caller-ID Conference drop Conferencing (3-way calling) Distinctive ring Do not disturb Hotline calling Incoming CallerID on/off IP URL dialing Message waiting indication Self-caller ID block Speed dial Voicemail message retrieval Warmline calling
IP Services	NAPT DHCP client PPPoE Programmable static routes ICMP redirect (RFC 792); Packet fragmentation VLAN support 802.1p/q
Call Routing & Services	Regular expression number matching Regular expression number manipulation Least Cost Routing Number blocking Short-Dialing Digit collection Distribution-Groups & Hunt-Groups 2nd call offering
Management	Browser configuration interface Multilevel security access TFTP & HTTP configuration & firmware loading SNMP v2 agent Syslog support
Power	100240 VAC (50/60 Hz)
Temperature	0 to 40C (32 to 104F)
Humidity	Humidity: 5 to 80% (non condensing)
Dimensions	20.8W x 3.4H x 16.5D cm (8.2W x 1.3H x 6.5D in.)
Weight	< 450 g (15.9 oz)
Compliance	EMC compliance: EN55022 and EN55024 Safety compliance: EN 50950 CE compliance FCC Part 15 Class B
