Description
Bogen PI5660W 60W 802.3bt PoE Injector
Powers high-wattage devices like the NQ-GA40P3 when your switch lacks 802.3bt ports.
Key Features
- Provides regulated 56VDC and 60W at 1.07A from a 100-240VAC, 47-63 Hz source
- 6', 18 AWG, NEMA 5-15P to IEC 60320 C-13 line cord included
- Maximum power consumption of 2.5A (RMS) for 90VAC and 1.2A (RMS) for 240VAC
- Entire unit measures 6.43" × 2.56" × 1.42"
- UL and C-UL listed
- IEC320 3-pin inlet input connector
- RJ45 output connector
- Pins 3, 6, 4, and 5 are positive
- Pins 1, 2, 7, and 8 are negative
