Description
Does your current network lack PoE but you need reliable power for high-performance CyberData paging amplifiers? The CyberData 011124 PoE Power Injector 802.3at is the straightforward solution. It injects up to 25 watts of power inline between your non-PoE switch and amplifier using standard Ethernet cable. No hub upgrade required—perfect for small businesses and enterprises that want powerful paging without ripping out their existing network.
Key Features
- Provides up to 25 watts of driving power to compatible CyberData amplifiers for louder, more effective paging
- Fanless design for quiet, reliable long-term use in any environment
- Built-in over-current, short-circuit, and overload protection for system safety
- Green mode for better energy efficiency
- Fully backward compatible with all 802.3af devices
- Simple inline installation between non-PoE switch and device via Cat 5 cable
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | 011124 |
| PoE Standard | 802.3at (PoE+) |
| Output Power | Up to 25W driving power (33.6W total output capability) |
| Output Voltage | 56V DC |
| Input Voltage | 90–264 VAC, 47–63 Hz |
| Dimensions | 5.51" L × 2.55" W × 1.42" H |
| Weight | 0.5 lbs |
| Operating Temperature | –20°C to +50°C (–4°F to 122°F) |
| Indicators | Green LED 1 (Input power ON), Green LED 2 (802.3at load detected), Green LED 3 (802.3af load detected) |
| Protections | Over-voltage/current, short-circuit, overload |
| Compliance | FCC Part 15 Class B, EN55022 Class B |
Compatible Devices: SIP Paging Amplifier (011324), InformaCast® Enabled Paging Amplifier (011403), SIP Loudspeaker Amplifier (PoE) (011405), InformaCast® Enabled Loudspeaker Amplifier (PoE) (011407), and earlier V2 models (011061, 011095, 011096, etc.).
