Description
Need reliable, crystal-clear communication where noise and weather try to shut everything down? The Fanvil A11 SIP Audio Intercom steps up for small businesses and enterprises that demand tough, hands-free audio at outdoor gates, loading docks, parking entrances, warehouses, or factory perimeters. With its powerful 5W speaker and smart noise-fighting tech, your team hears every word—even in high-wind or busy environments—while the rugged build shrugs off rain, dust, corrosion, and impacts. Plug it into your existing SIP system and you’re done.
The Telecom Spot Take
Facilities managers and IT directors love the Fanvil A11 because it solves the real pain of spotty outdoor intercoms without overcomplicating things. The turbine acoustic design plus dual-mic noise reduction cuts through background racket so conversations stay professional and safe. IP66 and IK10 ratings mean it laughs at rain, snow, dust, and knocks that destroy lesser units. Pair that with simple SIP integration, PoE power, and a wide -40 °C to 70 °C operating range, and you get 24/7 uptime with zero surprises. Perfect for anyone tired of replacing cheap door phones every season.
Key Features
- 5W high-power speaker with turbine acoustic design – pushes clear, loud audio that cuts through wind, traffic, and machinery noise so every announcement or conversation lands perfectly.
- Dual-microphone noise reduction with AEC/ANR/AGC/AVC – automatically cancels echo and background sound so callers on both ends enjoy natural, hands-free talk without shouting.
- IP66 dust- and water-proof + IK10 vandal-resistant rating – keeps working through rain, snow, dust storms, and impacts that would wreck ordinary equipment.
- Stainless steel front panel and aluminum alloy housing – resists corrosion while looking professional year after year in outdoor or industrial settings.
- 2 SIP lines with full-duplex hands-free operation – integrates instantly with your phone system; supports auto-answer, multicast broadcast, and one-touch calling.
- Flexible power and mounting – runs on PoE+ (IEEE 802.3at) or DC 12-24V/2A; wall-mount bracket included, flush-mount option available.
- Extra interfaces for real-world installs – line-out for external speakers, 2 short-circuit inputs/relay outputs for door/gate control, SD card slot for local recording or scheduled broadcasts, plus tamper alarm.
- Wide temperature range (-40 °C to 70 °C) – stays reliable from freezing loading docks to hot factory floors.
Technical Specifications
| Category | Details |
|---|---|
| Audio | Speaker: 5W high-power with turbine acoustic design Microphones: Dual array with advanced noise reduction (AEC/ANR/AGC/AVC) Full-duplex hands-free intercom |
| Network & SIP | Protocol: SIP 2.0 (2 lines) Ethernet: 1× RJ45 10/100 Mbps (PoE+) Power: PoE+ IEEE 802.3at or DC 12-24V/2A |
| Physical & Environmental | Dimensions: 100.95 × 100 × 45 mm (with wall bracket) Material: Stainless steel front panel + aluminum alloy housing Protection: IP66 (water/dust) + IK10 (vandal/impact) Operating temperature: -40 °C to 70 °C |
| Interfaces | Line-out port Short-circuit input × 2 Relay output (short-circuit output) SD card slot Tamper alarm switch |
Comparison at a Glance
- vs. basic consumer door intercoms: Those cheap units fail in rain or noise and lack SIP integration. The A11 stays loud, clear, and connected 24/7.
- vs. Fanvil A12: Similar rugged build but the A11 delivers the perfect balance of 5W power and compact size for most gate and perimeter jobs—without paying for the higher-wattage speaker you may not need.
FAQ
How loud is the speaker and will it work in a noisy warehouse?
The built-in 5W speaker with turbine acoustic design delivers clear audio that easily overcomes typical industrial background noise. Dual-mic noise reduction keeps both sides of the conversation crisp.
Is the A11 truly outdoor-ready?
Yes—IP66 dust- and waterproof plus IK10 vandal resistance, stainless steel panel, and aluminum housing let it handle rain, snow, dust, and impacts while operating from -40 °C to 70 °C.
Does it integrate with our existing phone system?
It supports standard SIP with 2 lines, auto-answer, multicast, and works right alongside your current VoIP setup—no extra hardware required.
Can I use it to control a gate or door?
Yes. Built-in relay outputs and short-circuit inputs let you trigger locks or gates directly from the intercom.
How is it powered and mounted?
Runs on standard PoE+ or optional DC 12-24V. Includes a wall-mount bracket; flush-mount bracket is available separately for cleaner installs.
Does it support local recording or announcements?
Yes—the SD card slot lets you record calls or schedule broadcasts without needing a server.
