Description
When your business needs dependable two-way video communication outdoors, the Fanvil A11V SIP Video Intercom steps up. It combines a sharp 4MP wide-angle camera with powerful 5W audio and tough-as-nails IP66/IK10 protection so you get clear video and voice even in rain, dust, extreme heat, or bitter cold. Facilities managers and IT teams love how easy it installs with PoE and how reliably it integrates with existing SIP systems. Whether you’re securing a loading dock, factory gate, or remote entrance, this compact unit keeps your team connected and your property protected—day or night, year-round.
The Telecom Spot Take
At The Telecom Spot we work with IT directors, facilities managers, and business owners every day who need intercoms that simply refuse to quit. The Fanvil A11V is purpose-built for exactly those real-world challenges: noisy loading zones, all-weather gates, and high-traffic industrial sites. Its 4MP camera with 131° diagonal view, HDR, and IR illumination cuts through glare and darkness while the turbine-designed 5W speaker and dual-mic array punch through background noise. Add the rugged stainless-steel faceplate, aluminum housing, and wide temperature range and you get a solution that keeps delivering crystal-clear video calls and door control without constant maintenance or downtime. It’s the kind of reliable, no-fuss performance our customers tell us makes their jobs noticeably easier.
Key Features
- 4MP wide-angle camera with IR & HDR – Captures sharp 1080p or 720p video across a 131° diagonal field of view so you see every detail clearly day or night, even in direct sunlight or low light (minimum illumination 0.05 Lux).
- Powerful 5W speaker + dual-mic noise reduction – Turbine acoustic design and advanced AEC, ANR, AGC, and AVC deliver loud, crystal-clear two-way audio that cuts through wind, traffic, and machinery noise.
- IP66 waterproof/dustproof & IK10 vandal-resistant – Stainless-steel panel and aluminum alloy housing stand up to rain, dust, impacts, and tampering so the unit keeps working in the harshest outdoor and industrial environments.
- Wide operating temperature (-40°C to +70°C) – Performs reliably from freezing winters to scorching summers without extra heaters or cooling.
- PoE+ power with flexible options – Single Ethernet cable for power and data (802.3at) or DC 12-24V; simple wiring saves time and money during installation.
- 2 SIP lines + rich I/O – Supports two simultaneous SIP accounts, relay output for door/gate control, 2 short-circuit inputs, audio line out, SD card recording, and tamper alarm for complete integration.
- Compact & easy to mount – Small footprint (100.95 × 100 × 45 mm) fits neatly on walls or posts; wall-mount standard, flush-mount available.
Technical Specifications
| Category | Specification |
|---|---|
| Camera | 4MP (1/2.9" CMOS), H.264, 1080p/720p, 131° diagonal FOV, HDR, IR illumination, min. 0.05 Lux |
| Audio | 5W speaker (turbine design), dual mic array with AEC/ANR/AGC/AVC, wideband codecs (G.722, Opus, etc.) |
| Protection | IP66 (water/dust), IK10 (vandal) |
| Operating Temperature | -40°C to +70°C |
| Power | PoE+ (802.3at) or DC 12-24V |
| SIP | 2 lines |
| Interfaces | Relay output, 2× short-circuit inputs, audio line out, SD card slot, tamper alarm |
| Dimensions | 100.95 × 100 × 45 mm |
| Mounting | Wall mount (flush optional) |
| Network | 10/100 Mbps Ethernet |
Comparison at a Glance
- Vs. basic audio-only SIP intercoms – Adds full 4MP video with night vision and HDR so you don’t just hear visitors—you see them clearly.
- Vs. standard consumer video doorbells – True IP66/IK10 rugged build and industrial temperature range mean it survives real outdoor abuse where plastic consumer models fail.
- Vs. larger video intercoms – Same pro-grade features in a compact 101 mm housing that installs faster and costs less to deploy across multiple gates or doors.
FAQ
How tough is the Fanvil A11V for outdoor use?
Extremely. IP66 keeps out water and dust while IK10 protects against vandalism—plus it runs from -40°C to +70°C without extra equipment.
Does it work with my existing phone system?
Full SIP compatibility with 2 lines means it integrates seamlessly with most VoIP platforms and PBXs.
Can I control gates or doors remotely?
Absolutely. Built-in relay output lets you unlock gates or doors directly from any SIP video call.
Is installation complicated?
Not at all. PoE+ means one Ethernet cable handles power and data; the compact size and included wall-mount bracket make it quick to put up.
Does it record video?
Yes—onboard SD card slot lets you store footage locally for later review.
What video quality can I expect at night?
Infrared illumination plus HDR delivers clear 1080p or 720p video even in near-total darkness.
