Description
You need a handset that stays on the company system while people walk the floor - the Fanvil LINKVIL W620H does that job. It joins to a LINKVIL W710H base. It does not join office Wi-Fi.
You get a 2.4-inch color screen, a PTT key, and a 3000 mAh battery. Lab talk time is up to 13 hours. Standby is up to 240 hours. With a W710H, ideal coverage is up to 60 meters indoors and up to 350 meters outdoors. Bluetooth 5.0 and a Type-C headset jack keep both hands free.
Pick this if you already have a W710H mutli-cell system, or you are ready to add one.
The Telecom Spot Take
Buy the W620H if people walk the building and still need a company extension. It is the longer-shift handset for a W710H system. You get a 2.4-inch screen, 16 DSS keys, a PTT key, and a 3000 mAh battery rated up to 13 hours of talk. It is not a Wi-Fi phone. If you already have office Wi-Fi and no W710H, the W620W is the better fit.
Key Features
- Made for a W710H base, not guest Wi-Fi. This is an 802.11ah handset. Pair one unit with the reset button on the W710H. Load a batch from the W710H web page.
- Handoff as people move. Roaming and switching are built in. Ideal coverage with a W710H is up to 60 meters indoors and up to 350 meters outdoors. Add bases when one cell is not enough.
- A long shift on one charge. The removable 3000 mAh battery is rated up to 13 hours of talk and up to 240 hours of standby in lab tests. Charge on the cradle or by Type-C at 5 V / 2 A.
- PTT and 16 DSS keys. One PTT key places a one-touch call. Sixteen DSS keys hold speed dials and transfers so staff skip the menu.
- Clearer calls in loud rooms. Two mics, noise cancellation, echo cancellation, and wideband G.722 and Opus keep a forklift aisle or clinic hall from wiping out the call. The speaker is 2 W.
- You feel the ring. Vibration helps on a noisy floor or a belt clip. Orange, green, and red lights show status at a glance.
- Headset two ways. Bluetooth 5.0 can answer, end, mute, redial, and change volume. A Type-C jack covers a wired headset.
- Four SIP lines, one internal extension. Internal calls can run without a SIP proxy. A 6-way audio conference covers a quick huddle.
- Built to be carried. Belt clip is in the box. Safe drop height is 1.8 meters. Size is 160 x 53 x 16 mm at 251 g. It runs from −10 °C to 45 °C.
Technical Specifications
| Item | Detail |
|---|---|
| Brand / model | Fanvil LINKVIL W620H Wireless Phone |
| SKU | W620H |
| UPC | 889837003886 |
| Role | Portable wireless handset for W710H multi-cell systems |
| Radio | 802.11ah |
| Coverage with W710H | Up to 60 m indoors, up to 350 m outdoors, ideal conditions |
| Deployment | Quick join via W710H reset button; batch deploy via W710H web interface |
| Wireless encryption | WPA2-PSK |
| Screen | 2.4 in TFT color, 240 x 320; screensaver, custom background, backlight adjust, screen-off during calls |
| Keys | 12 digit keys, 4-way navigation + OK, 7 function keys (dial, hang-up, hands-free, phone book, mute, transfer, DSS), 2 volume keys, 2 soft keys, 1 PTT key, white backlight |
| DSS | 16 custom DSS keys |
| Status light | Orange, green, red |
| SIP / extension | 4 SIP lines, 1 internal extension |
| Call features | Answer, reject, waiting, switch, forward, speed dial, intercom, anonymous call hide/block, 6-way audio conference, internal extension without SIP proxy, emergency call, caller ID, DND and timed DND, PTT one-touch, auto answer, voicemail MWI, memo |
| Phone book | 1,000 local contacts; XML/LDAP remote phone book, 1,000 entries; incoming and outgoing allow/restrict lists |
| Call logs | 600 |
| Audio | 2 W speaker, 2 microphones, intelligent noise cancellation, acoustic shield, AEC, AGC, VAD / CNG / BNE, packet loss concealment |
| Codecs | Narrowband: G.711A/U, G.729, G.729A, G.729B, G.729AB, iLBC. Wideband: G.722, Opus |
| DTMF | In-band, RFC2833, SIP INFO |
| Bluetooth | 5.0; headset answer, end, mute, redial, volume |
| Ports | USB 2.0 Type-C; Type-C headset jack; Type-C plus 2 contact pins for charging |
| Security | SRTP, TLS 1.2, WPA2-PSK, keypad lock, menu encryption |
| Protocols | DHCP, SNTP |
| Maintenance | Firmware upgrade via Manager or USB disk; packet capture via Manager; log export via USB disk |
| Languages | English, Chinese, Traditional Chinese, Russian, Italian, German, Japanese, French, Hebrew, Spanish, Catalan, Basque, Galician, Turkish, Slovenian, Czech, Dutch, Korean, Ukrainian, Portuguese, Arabic, Thai |
| Battery | 3000 mAh removable; up to 13 hours talk, up to 240 hours standby (laboratory data) |
| Charging | Charging base and Type-C; DC 5 V / 2 A |
| Drop | 1.8 m safe drop height |
| Environment | Operating −10 °C to 45 °C; storage −20 °C to 60 °C; humidity 5–95% non-condensing |
| Size / weight | 160 x 53 x 16 mm; 251 g |
| In the box | W620H handset, 5 V / 2 A adapter, charging base, belt clip, rechargeable battery, quick installation guide |
| Not in the box | W710H base station (required for the radio system) |
FAQ
Does the W620H work on normal office Wi-Fi?
No. It pairs with a LINKVIL W710H base. If you want a portable phone on 2.4 GHz and 5 GHz Wi-Fi 6, buy the W620W.
What do I need before this handset is useful?
A W710H base. The cradle in the box only charges the phone. Join one handset with the reset button on the W710H, or load a batch from the web page.
How far can someone walk?
With a W710H, ideal figures are up to 60 meters indoors and up to 350 meters outdoors. Walls, racking, and metal cut that down. Add bases and use roaming for a bigger site.
How long does the battery last?
Lab data lists up to 13 hours of talk and up to 240 hours of standby on the 3000 mAh battery. Signal, screen use, and Bluetooth change that. Charge on the cradle or by Type-C at 5 V / 2 A.
