Description
Your business deserves Wi-Fi that just works—fast, far-reaching, and ready for dozens of devices at once. The Grandstream GWN7670E is a dual-band Wi-Fi 7 (BE3600) access point built specifically for small-to-medium businesses that need next-level performance without the complexity. With 3.6Gbps aggregate wireless throughput and support for up to 512 concurrent clients across a massive 175-meter coverage area, it turns crowded conference rooms, busy retail floors, and multi-classroom environments into smooth, high-speed networks.
The Telecom Spot Take
Here’s the straight talk from our team: the GWN7670E stands out for customers who want Wi-Fi 7 power at a practical price and scale. Its 5 GHz band uses Xtra Range 2.0 technology to punch through walls and deliver stronger signals where older access points fade. With a single 2.5GbE PoE+ port and an embedded controller that manages up to 50 APs right out of the box, you get enterprise-grade management without extra hardware or cloud-only headaches. Whether you’re upgrading a single office or rolling out across multiple locations, this AP gives your team the speed, capacity, and coverage that keeps users productive and happy—exactly what our customers tell us matters most.
Key Features
- Blazing 3.6Gbps aggregate wireless speeds — Your users get smooth 4K streaming, video calls, and large file transfers even when the office is packed.
- Supports up to 512 concurrent clients — Ideal for high-density environments like open offices, retail stores, or schools—no more slowdowns when everyone connects at once.
- 175-meter coverage with Xtra Range 2.0 on 5 GHz — Reliable signal reaches farther and penetrates obstacles better, reducing dead zones without extra access points.
- Wi-Fi 7 advanced technologies — Multi-Link Operation (MLO), 4K-QAM, Multi-RU, and preamble puncturing deliver faster data rates, better efficiency, and less interference.
- Simple, flexible management — Use the built-in web UI controller (up to 50 APs), GDMS cloud platform, on-premise GWN Manager, or the mobile GDMS app—choose what fits your team best.
- Enterprise-grade security — WPA3 encryption, unique per-device certificates, secure boot, and digital signature lockdown keep your network protected right from day one.
Technical Specifications
| Category | Details |
|---|---|
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax/be (Wi-Fi CERTIFIED 7™) |
| Wireless Throughput | 3.6Gbps aggregate 2.4 GHz: 688Mbps (2×2:2 MU-MIMO) 5 GHz: 2,882Mbps (3×3:2 MU-MIMO) |
| Wired Throughput | 2.5Gbps aggregate |
| Client Capacity | Up to 512 concurrent clients |
| Coverage Range | Up to 175 meters (environment-dependent) |
| Network Interfaces | 1 × 2.5 GbE RJ45 port (PoE input) |
| PoE / Power | 802.3at PoE+; maximum consumption 17W |
| Antennas | 5 internal single-frequency antennas (2.4 GHz: 2 × 3.5 dBi; 5 GHz: 3 × 5.5 dBi) |
| SSIDs | 32 total (16 per radio) |
| Mounting | Ceiling, wall, or junction box mount |
| Dimensions | Ø220 mm × 48.5 mm |
| Management | Embedded controller (up to 50 APs), GDMS Networking (cloud), GWN Manager (on-premise), GDMS mobile app |
| Security | WPA2/WPA3 Personal & Enterprise, WPA3-OWE, anti-hacking secure boot, digital signatures, unique certificate per device |
Comparison at a Glance
- vs GWN7670: Same 3.6Gbps wireless speeds but the GWN7670E supports twice the clients (512 vs 256) and uses a more powerful 3×3:2 on 5 GHz for better performance in denser areas.
Frequently Asked Questions
What makes the GWN7670E better for high-density environments?
It handles up to 512 clients at once with Wi-Fi 7 technologies that reduce congestion and keep every connection fast and stable.
Does it need a separate controller?
No—the embedded controller in the web UI can manage up to 50 GWN access points right away, or scale with Grandstream’s free cloud or on-premise platforms.
How far does the coverage really reach?
Up to 175 meters thanks to Xtra Range 2.0 technology on the 5 GHz band, giving you strong signals even through walls and across larger spaces.
Is PoE+ required?
Yes, it uses 802.3at PoE+ (max 17W) for easy single-cable installation—no extra power adapter needed.
Can I manage multiple locations from one dashboard?
Absolutely—GDMS Networking gives you cloud-based control over all your GWN7670E units from anywhere, while GWN Manager keeps everything on-premise if preferred.
Who is this access point best for?
IT directors and facilities managers at SMBs, retail shops, offices, and schools who need reliable, high-capacity Wi-Fi 7 performance without breaking the budget.
