Description
The Grandstream GWN7673 is an enterprise-grade BE5000 Wi-Fi 7 access point built for businesses that need reliable, high-capacity wireless without the complexity of higher-end tri-band models. It combines 5 Gbps aggregate wireless throughput with a 2.5 Gbps wired uplink, dual-band 2.4 GHz 2×2:2 and 5 GHz 3×3:3 MU-MIMO, and support for up to 512 concurrent clients. Our customers—IT directors, facilities managers, and business owners at growing SMBs and mid-size enterprises—get the speed and density handling needed for modern offices, classrooms, or retail spaces while keeping management simple through free cloud or on-premise tools.
The Telecom Spot Take
This model stands out for medium-scale, medium-to-high density environments. The 3×3:3 configuration on 5 GHz plus Wi-Fi 7 features (MLO, 4K QAM, MRU, and preamble puncturing) give our customers more simultaneous capacity than basic dual-band Wi-Fi 7 units while staying more affordable than full tri-band options. Self-adapting PoE+ power, 32 SSIDs, and up to 1,000 PPSK accounts make secure guest and staff segmentation straightforward. Pair it with Grandstream’s free GDMS Networking or GWN Manager and you get centralized visibility without ongoing licensing fees—exactly what procurement teams and IT leaders look for when scaling wireless across one or multiple sites.
Key Features
- 5 Gbps aggregate wireless throughput with 2.5 Gbps wired backhaul – Handles heavy concurrent traffic from laptops, phones, and IoT devices so users stay productive during peak hours.
- Dual-band 2.4 GHz 2×2:2 and 5 GHz 3×3:3 MU-MIMO with MLO, 4K QAM, MRU, and preamble puncturing – Delivers higher efficiency and lower latency for video calls, cloud apps, and real-time collaboration.
- Supports 512 concurrent Wi-Fi client devices – Ideal for open offices, training rooms, or retail floors where many devices connect at once.
- Up to 1,000 PPSK accounts – Enables individualized, secure access for staff or guests without complex RADIUS setups.
- Advanced QoS, mesh networking, and captive portals – Prioritizes voice and video traffic while supporting flexible network designs.
- BLE 5.3 for location services – Supports Bluetooth Low Energy applications when location or asset tracking is needed.
- Self-power adaptation on PoE+ (802.3at/af) – Automatically adjusts power for reliable operation from a single cable.
- Flexible free management – Embedded controller for up to 50 local APs, plus unlimited cloud management via GDMS Networking or on-premise GWN Manager.
- Strong security foundation – Anti-hacking secure boot, digital signatures, unique device certificates, and random default passwords protect the network from the first power-on.
- Indoor mounting flexibility – Wall, ceiling, or junction-box install with the included multi-pattern bracket for clean deployments.
Technical Specifications
| Specification | Details |
|---|---|
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax/be (Wi-Fi 7) |
| Aggregate Wireless Throughput | 5 Gbps |
| Aggregate Wired Throughput | 2.5 Gbps |
| 2.4 GHz Throughput | 688 Mbps (2×2:2 MU-MIMO) |
| 5 GHz Throughput | 4323 Mbps (3×3:3 MU-MIMO) |
| Concurrent Clients | Up to 512 |
| SSIDs | 32 total (16 per radio) |
| Network Interface | 1 × 2.5 GbE RJ45 (PoE input) |
| PoE | 802.3at/af; max power consumption 16 W |
| Antennas | 5 single-frequency (2.4 GHz: 2 × 3.5 dBi; 5 GHz: 3 × 5.5 dBi) |
| Frequency Bands | 2.4 GHz: 2400–2483.5 MHz; 5 GHz: 5150–5850 MHz |
| Coverage | Up to 175 meters (environment dependent) |
| Security | WPA2/WPA3 Personal & Enterprise, OSEN, OWE, unique cert + random password, secure boot & digital signature lockdown |
| Management | Local Web UI (up to 50 APs), GDMS Networking (unlimited), GWN Manager (on-premise) |
| Dimensions | Ø220 mm × 48.5 mm |
| Mounting | Indoor wall, ceiling, or junction box |
| Bluetooth | BLE 5.3 |
Comparison at a Glance
- vs. Grandstream GWN7670 (lower-tier dual-band Wi-Fi 7): GWN7673 offers higher 5 GHz spatial streams (3×3:3 vs 2×2:2), more concurrent clients (512 vs 256), and higher aggregate wireless throughput (5 Gbps vs 3.6 Gbps) for denser environments.
- vs. Grandstream GWN7672 (tri-band Wi-Fi 7): GWN7673 provides a simpler dual-band design with strong 5 GHz capacity and lower cost while still supporting 512 clients; the GWN7672 adds the 6 GHz band and higher total throughput for the most demanding multi-gig deployments.
- Both alternatives share the same free management platforms, security features, and 175-meter class coverage, so the choice centers on density needs and budget.
FAQ
What environments is the GWN7673 best suited for?
Medium-scale offices, schools, hotels, and retail spaces with medium-to-high user density that need solid Wi-Fi 7 performance without tri-band complexity.
How many devices can it support at once?
Up to 512 concurrent Wi-Fi clients.
Does it support cloud management?
Yes. Free unlimited management is available through GDMS Networking, plus local Web UI and on-premise GWN Manager options.
What power source does it use?
Standard PoE+ (802.3at/af) with automatic power adaptation; maximum consumption is 16 W.
Can it handle secure guest access easily?
Yes. It supports up to 1,000 PPSK accounts plus captive portals for straightforward individualized access.
Is the GWN7673 Wi-Fi 7 certified?
Yes. It integrates Wi-Fi 7 Certified connectivity with MLO, 4K QAM, MRU, and preamble puncturing.
