Description
- 9 Fixed Feature Keys: Conference, Transfer, Drop, Hold, Redial, Mute, Volume up & down, Speaker, Voice Mail
- Message Waiting Indicator
- Full-duplex speaker phone
- Built-in headset jack
- Multiple language support built-in: English, French, Italian, Spanish & KataKana
- 8 Personalized ring patterns
- G.711, G.729a/B Voice CODECs
- QoS Options of - UDP Port Selection, DiffServ and 802.1p/B (VLAN)
- Single 10/100 BaseT Ethernet port
- Support for Simple Network management Protocol (SNMP)
- Hearing Aid Compatible
- Microsoft NetMeeting Compatible
- IP Address Assignment - DHCP Client or Statically Configured
- Downloadable firmware for future upgrades
- Wall Mountable with included desk/wall mount stand
- 5 x 29 character (168 x 80 pixel 4-grayscale) display
- 24 Programmable call appearance/feature keys (arranged in 4 switchable display pages of 6 matching the 6 physical display buttons)
- IP Office Interactive menus can be invoked from appropriately programmed DSS keys, and these menus will utilize the 6 programmable feature keys and the Exit fixed function key
- Connects to IP Office via the LAN
- Integrated Switched ports for connection of PC:
- Auto-negotiation provided separately for each port
- Full Duplex Ethernet connectivity
- 802.3 Flow Control on full duplex ports
- Phone has priority over PC port at all times
- Power Options: IEEE 802.11af Power over Ethernet (PoE) or optional individual power supply unit (1151C1/C2).
- Avaya Communication Server - TN2302AP and TN799B/C (not needed on S8300 Media Server with G700 Media gateway)
- IP403/406/412/Small Office Edition - Version 2.0 or higher with available IP Station Port
