Dolby IP Conference Phone (VCP9000-5A)
The Dolby Conference Phone delivers impressive flexibility and a streamlined design for great sound in huddle spaces up to boardrooms. Paired with a Dolby Voice enabled service, its innovative technology delivers stunning audio that improves comprehension and encourages more natural conversation.
|
|
Dolby IP Conference Features
Operating Modes
- IP Phone mode
- Dolby Voice mode*
Audio features available in both IP phone and Dolby Voice modes
- Wideband (HD) audio: 160 Hz–8 kHz
- 20-ft (6.1 m) microphone pickup range
- 360 degree audio capture
- Speaker volume: adjustable to 88 dB SPL peak volume at ½ m (1.6 ft) Full duplex
- Noise suppression
- Acoustic echo cancellation
Dolby Voice Mode* features
- *Requires a Dolby Voice enabled conferencing service
- Preconfigured access to Dolby Voice enabled conferencing services (no need to dial access phone number)
- One-touch meeting start when phone is in personal mode
- IP connection to Dolby Voice enabled conferencing services
- Voice separation: captures all the voices in the room and maintains separation of voices through the server to Dolby Voice enabled endpoints; places individual remote conference participants in distinct virtual locations in the room
- Viewable roster of meeting attendees and active speaker
- Touchscreen meeting management: mute/unmute and eject participants, lock meeting
IP Phone Mode features
- For interoperability details, please visit dolby.com/interop.
- IETF SIP (RFC 3261 and companion RFCs)
- Audio codecs: G.711a/G.711u/G.722/G.729ab
- Local three-way conferencing
- Conference, join, split, hold, resume, mute
- Call waiting
- Call transfer, hold, divert (forward), and pickup
- Called, calling, connected party information
- Recent call history
- Searchable contact directory with touch dialing
- Do Not Disturb function
User interface
- Touch interface with swipe support
- 4.3-in. (10 cm) LCD display with 480 × 272 resolution
- LED halo: blue halo when in a Dolby Voice conference; green halo when in an IP
- telephony call; red halo when muted
- External tactile keys
- Mute, volume control
Network and provisioning
- Ethernet 10/100 Base-T
- IP address configuration: DHCP and Static IP IPv4 compatible
- Time synchronization with SNTP server
- Bulk provisioning, management, and field-upgradable firmware through Dolby
- Conferencing Console software
- QoS Support: IEEE 802.1p/Q tagging (VLAN), Layer 3 TOS and DSCP RTCP support (RFC 1889)
- LDAP directory support
- Web proxy auto-detection and proxy auto-configuration support
- Network and Provisioning (continued)
- Supports Dolby Voice and IP telephony calls on separate voice and data VLANs
- Hardware diagnostics
- Status and statistics
Security
- Transport Layer Security (TLS) for authentication and encryption of SIP signaling SRTP encryption for media
- IEEE 802.1x Network Access Control
Power
- IEEE 802.3af Power over Ethernet, Class 3 maximum 13 W
Physical Dimensions
- H × W × D: 2.2 × 11.8 × 12.6 in. (5.6 × 30 × 32 cm)
- Weight Net: 4 lb (1.8 kg)
Dolby Conference Phone ships with:
- 1 × PoE conference phone unit
- 1 × Quick Start Guide
- 1 × 25-ft (7.6 m) network cable
- Limited new product warranty: 1 year
Dolby satellite microphone kit (optional)
- Pickup range extended by up to 6.5 ft (2.0 m) per Dolby satellite microphone kit ships with 2 × Dolby satellite microphones and 2 × 6.5-ft (2.0 m) cables
