Description
Need a video intercom that cuts through noise and delivers sharp video even in tough outdoor conditions? The Fanvil A12V gives your team crystal-clear two-way communication with a loud 10W speaker and a high-definition 4MP starlight camera. Built tough with IP66 weatherproofing and IK10 vandal resistance, it’s ready for busy commercial entrances, gates, or loading docks. Simple SIP integration means it works right alongside your existing phone system—no complicated setup required.
The Telecom Spot Take
Customers love the Fanvil A12V because it solves real-world pain points like poor audio in noisy areas and unreliable video at night. The 10W speaker with turbo sound chamber blasts clear sound up to 5 meters away, while advanced dual-microphone noise reduction keeps conversations intelligible even near traffic or machinery. Its stainless-steel panel and aluminum-alloy body stand up to weather, impacts, and corrosion, so you get years of dependable service with minimal maintenance. If you want secure door access control plus high-quality video monitoring in one rugged unit, this is the practical choice that just works.
Key Features
- Powerful 10W speaker with turbo sound chamber – Delivers up to 100dB broadcast and crystal-clear hands-free calls that carry up to 5 meters, so visitors and staff hear every word even in loud environments.
- Advanced dual-microphone noise reduction – Uses AEC, ANR, AGC, and AVC algorithms to capture clean audio in challenging conditions, making conversations easy and professional.
- 4MP starlight HD camera with wide-angle view – Provides sharp 1080P or 720P video with 122° diagonal field of view, built-in infrared lighting, and HDR for excellent imaging day or night.
- Rugged IP66/IK10 protection – Stainless-steel panel and aluminum-alloy shell resist water, dust, and vandalism, plus it operates from -40°C to 70°C—perfect for outdoor or harsh indoor use.
- 2 SIP lines and full VoIP compatibility – Works seamlessly with Asterisk, 3CX, Broadsoft, and other mainstream platforms for easy integration into your existing phone or intercom system.
- Rich interfaces for access control – Includes short-circuit outputs for electric locks, Wiegand, RS-485, USB, line-out audio, and SD card slot so you can expand security features exactly how your business needs.
- Convenient extras – One programmable DSS key, self-check function, remote pickup, and MP3 broadcasting make daily operation simple and maintenance quick.
Technical Specifications
Audio
- Codecs: Narrowband – G.711a/u, G.729, iLBC, G.723, G.726; Wideband – G.722, Opus
- Speakerphone: Full-duplex hands-free with AEC
- Speaker: 10W with turbo sound chamber (up to 100dB broadcast)
- Voice pickup range: Up to 5 meters
Video
- Sensor: 1/2.9” color CMOS
- Pixels: 4 Mega-pixel starlight HD camera
- Video coding: H.264
- Resolution: 720P / 1080P
- Minimum illumination: 0.05 Lux (with infrared illumination)
- Viewing angle: Diagonal 122°, Horizontal 103°, Vertical 54.8°
- Built-in infrared light and HDR
Network
- Ethernet: 10/100 Mbps (PoE+ IEEE 802.3at Class 4)
- IP mode: IPv4 / IPv6 / IPv4 & IPv6
- Configuration: Static IP, DHCP, PPPoE
- VPN: L2TP / OpenVPN
- VLAN: Supported
Protocols
- SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
- RTP/RTCP/SRTP
- STUN, DHCP, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069
Interfaces
- 1× RJ45 (PoE+)
- 2× short-circuit input ports
- 2× short-circuit output ports (built-in relay, max DC30V/2A or AC125V/0.5A)
- 1× line-out audio (1000Ω impedance)
- 1× Wiegand port
- 1× RS-485 port
- 1× USB port
- 1× SD card slot (TF card)
- 1× DC power input (12V~24V/2A)
- 1× tamper alarm switch
Physical
- Dimensions: 205 × 120 × 54.5 mm (with wall-mounted bracket)
- Weight: 1.72 kg (net)
- Material: Stainless-steel panel + aluminum-alloy shell
- Protection: IP66 waterproof/dustproof and IK10 anti-riot (except lens)
- Installation: Wall-mounted or flush-mounted
- Operating temperature: -40°C to 70°C
- Storage temperature: -40°C to 70°C
- Humidity: 10~95% (non-condensing)
FAQ
Is the Fanvil A12V suitable for outdoor use?
Yes—its IP66 waterproof and dustproof rating plus IK10 vandal resistance make it ideal for exposed entrances, gates, or loading areas in any weather.
What power options does it support?
It runs on PoE+ (IEEE 802.3at) or optional standard DC 12V~24V/2A power, giving you flexible installation choices.
How clear is the video at night?
The 4MP starlight camera with built-in infrared lighting and HDR delivers sharp 1080P or 720P images even in very low light (0.05 Lux minimum).
Can it control door locks?
Absolutely—two short-circuit output ports with built-in relays let you manage electric locks, alarms, or other access devices directly.
Is it compatible with my existing phone system?
It supports 2 SIP lines and works with popular platforms like Asterisk, 3CX, Broadsoft, and more—no extra hardware needed.
Does it record video or audio?
Yes—the built-in SD card slot supports local recording and preset MP3 broadcasting for announcements or logs.
