Description
Running a compact office, small retail location, or home-based hybrid workspace and need reliable power for your IP phones, Wi-Fi access points, security cameras, and other devices without overspending? The Grandstream GWN7801P Pro is the perfect entry-level pro switch. This Layer 2++ managed unit gives you 8 Gigabit PoE+ ports with a solid 120W total budget (up to 30W per port) plus two ultra-fast 2.5G SFP uplinks—everything you need for smooth VoIP calls, video streaming, and cloud applications in one quiet, compact, rack-mountable package.
The Telecom Spot Expert Review
The GWN7801P Pro is our top recommendation for locations with 5–10 PoE devices where you need dependable 30W-per-port power but don’t need the larger 16- or 24-port models. The 120W budget feels very generous in real-world use thanks to smart dynamic allocation and priority settings.
What we love:
- All 8 ports deliver true PoE+ (up to 30W) with no guesswork about which ports can power what.
- Two 2.5G SFP uplinks give you future-proof backbone speed without extra modules.
- Free lifetime GDMS cloud management means you can monitor everything from your phone.
Pro setup tip from our team: When mixing Yealink phones, Grandstream APs, and IP cameras, enable LLDP-MED and set port priorities in the WebUI. It takes about 10 minutes and automatically protects your most important devices if you ever approach the 120W limit.
Pros: Excellent 120W PoE+ budget, fast 2.5G uplinks, completely fanless and silent, free cloud management, easy WebUI. Cons: Only 8 ports (perfect for small setups—scale up to the 7802P if you need more).
Expert rating: 4.9/5 — our go-to 8-port switch for most small businesses that want solid power + performance without complexity.
Key Features
- 8 Gigabit PoE+ Ports – Every port supports up to 30W (IEEE 802.3af/at) with smart dynamic power allocation.
- 120W Total PoE Budget – Powers multiple phones, cameras, and access points at full strength.
- 2x 2.5Gigabit SFP Uplinks – Future-proof fiber or DAC connections for ultra-fast backbone links.
- Layer 2++ Capabilities – Advanced VLANs (4K), QoS, IGMP/MLD snooping, ACLs, and static routing.
- Flexible Management – Free GDMS cloud, embedded WebUI controller, GWN Manager, or CLI.
- Enterprise Security – 802.1X, ARP inspection, DoS protection, port security, and more.
- Built for Reliability – Fanless design, redundant power support, surge protection, and compact 1U size.
Comparison to Similar Models
Here’s how the GWN7801P Pro stacks up (all specs from official Grandstream datasheets):
| Model | PoE Ports | PoE Budget | Uplinks | Switching Capacity | Stacking | Best For |
|---|---|---|---|---|---|---|
| GWN7801P Pro (this one) | 8 PoE+ | 120W | 2× 2.5G SFP | 26 Gbps | No | Compact small-office setups |
| Grandstream GWN7802P Pro | 16 (4x PoE++ + 12x PoE+) | 250W | 2× 10G SFP+ | 72 Gbps | No | Growing offices needing flexibility |
| Grandstream GWN7803PL Pro | 24 PoE+ | 250W | 2× 10G SFP+ | 88 Gbps | No | Balanced 24-port deployments |
| Grandstream GWN7803PH Pro | 24 PoE++ | 400W | 2× 10G SFP+ | 88 Gbps | No | High-power 24-port setups |
Choose the GWN7801P Pro when you want the perfect compact mix of power, speed, and value—especially if you’re already using Grandstream phones or APs.
Technical Specifications
- Ports: 8 × 10/100/1000 Mbps PoE+ RJ45 + 2 × 2.5G SFP
- PoE: IEEE 802.3af/at, 30W per port max, 120W total budget
- Switching Capacity: 26 Gbps
- Non-blocking Throughput: 13 Gbps
- Forwarding Rate: 19.35 Mpps
- MAC Address Table: 8K
- VLANs: 4K (port-based, 802.1Q, MAC-based, Voice, QinQ)
- Management: WebUI, GDMS Cloud, GWN Manager, CLI
- Power: 100-240V AC, integrated power supply
- Dimensions: 330 × 175 × 44 mm (compact rack/wall/desktop mount)
- Weight: ~1.8 kg
- Operating Temp: 0°C to 45°C
- Warranty: 3 years
