Description
Need an easy way for visitors to reach you from the front door, loading dock, or gate without picking up a handset? The Viking W-2000A Handsfree Doorbox delivers clear two-way communication right from your existing phone system.
Just press the big “Call” button and it rings your phones with a professional ring cadence you can customize. Talk hands-free through the built-in speaker and mic – perfect for busy offices, warehouses, gas stations, or residential gates.
It connects directly to an unused analog trunk or FXO port on most phone systems (including many VoIP setups with a gateway). For single-line homes or when you want to add door strike control, pair it with the Viking C-1000B controller. Built tough in a UV-stable plastic housing with weather-resistant features, this doorbox stands up to daily use indoors or in protected outdoor spots.
Our Expert Take: Choose the W-2000A when you want easy surface mounting and strong performance without paying for full stainless steel toughness. If your location sees heavy abuse, step up to the W-3000. For basic home use with door strike control, the C-1000B + W-2000A combo is hard to beat. For full outdoor exposure, consider the W-2000A-EWP model with enhanced IP66 protection.
Key Features
- Handsfree Operation — No handset to pick up; just press Call and talk naturally
- Loud & Clear Audio — High-output speaker with volume control plus adjustable microphone volume
- Push-to-Talk Mode — Ideal for noisy locations to reduce feedback and improve clarity
- Customizable Ringing — Choose standard, double, short/short/long, or short/long/short cadence; select 2, 3, 10, or 30 rings
- Strong Ring Output — Built-in 20 Hz ring generator (up to 6.0 REN load)
- 40V Talk Battery — Provides clear voice even on longer wire runs
- Weather-Resistant Design — Sealed switch (IP67), Mylar speaker, self-draining mic, and gaskets – great for protected outdoor use
- Easy Surface Mount — Light grey UV-stable Geloy plastic chassis with clean black graphics
- Flexible Connections — Works with phone system trunk/FXO ports or Viking C-1000B controller for 1-2 doorboxes on one line
- Long Reach — Up to 6,300 ft line loop with 24 AWG wire
Technical Specifications
- Power: 120V AC to 13.8V AC 1.25A UL listed adapter (included)
- Dimensions: 5.5” x 4.5” x 1.7” (140mm x 115mm x 43mm)
- Shipping Weight: 4 lbs (1.81 kg)
- Operating Temperature: -15°F to 130°F (-26°C to 54°C)
- Humidity: 5% to 95% non-condensing
- Ringer Output: 20 Hz, 6.0 REN maximum
- Talk Battery: 40V
- Maximum Line Loop: 6,300 ft (1.9 km) with 24 AWG twisted pair
- Power Run Length (CAT5): 150 ft (1 pair), 300 ft (2 pair), 450 ft (3 pair)
- Connections: 4 gel-filled butt connectors
- Chassis: Impact-resistant UV-stable light grey Geloy plastic
