Description
Combine upscale oil rubbed bronze styling with VoIP door entry and full outdoor weather protection in one compact package — the Viking E-60-BN-IP-EWP delivers SIP-compatible handsfree communication with Enhanced Weather Protection rated to meet IP66 standards.
This slim entry phone fits a standard double gang electrical box and runs entirely on PoE from your existing network cable. VoIP audio detection means no push-to-talk frustration, and Automatic Noise Canceling keeps calls clear even next to busy roads or in noisy parking structures. EWP construction — including sealed gaskets, gel-filled connectors, and potted circuitry — ensures reliable performance through rain, snow, and high humidity. The onboard 2-amp relay controls door strikes or access gates instantly on a touch-tone command.
Our Expert Take: When the entrance is exposed to weather and the aesthetic needs to match upscale bronze hardware, the E-60-BN-IP-EWP is the ideal solution. It pairs well with high-end residential communities and boutique commercial properties where the standard E-60-BN-IP would be at risk from rain exposure.
Key Features
- Enhanced Weather Protection (EWP) designed to meet IP66 ingress protection
- SIP compliant – works with most VoIP PBX and hosted systems
- PoE powered (Class 1, <4 watts)
- Compact flush mount – fits standard double gang electrical box
- VoIP audio detection – no push-to-talk required
- Automatic Noise Canceling (ANC)
- 2-amp relay contacts for door strike or gate control
- Blue LED indicator for visual call feedback
- Dials up to 5 programmable numbers; cycles on busy or no-answer
- Remotely programmable; extended temperature range: -40°F to 140°F
Technical Specifications
- Power: PoE Class 1 (<4 watts)
- Protocol: SIP 2.0
- Weather Protection: IP66 (EWP)
- Relay: 2A SPDT
- Temperature: -40°F to 140°F
- Finish: Oil rubbed bronze; 18-gauge stainless steel faceplate
