Description
Yealink MeetingBar A40 with CTP25 Touch Panel – Open Box
Condition: Open Box — Like new. Fully inspected, tested, and verified in working order.
Includes all boxes, manuals, and all standard accessories for the A40-031 bundle (CTP25 touch panel included).
The Yealink MeetingBar A40 is an integrated video collaboration bar designed for small to medium meeting rooms. Its dual 48MP camera system delivers crisp 4K video with Auto Framing, Speaker Tracking, IntelliFocus, Multi-focus Framing, and Smart Gallery (Zoom Rooms only) so every participant is seen clearly.
Dual 48MP Cameras with Intelligent Framing
The A40 dynamically adjusts framing as participants enter, move, or present, keeping remote attendees engaged with a natural, in-room perspective—without manual camera control.
Clear Audio for Natural Conversation
An 8-MEMS microphone array provides a 6 m pickup range with AI noise reduction, while dual 10W speakers deliver balanced room sound. For larger tables, add up to two expansion microphones (sold separately).
CTP25 Touch Panel Included
This A40-031 bundle includes the CTP25 touch panel, enabling one-touch join, call controls, camera adjustments, volume, and layout changes directly from the table—no laptop required.
Run native Microsoft Teams Rooms or Zoom Rooms on the bar, or switch to BYOD when needed. Multi-stream IntelliFrame with Copilot is available in Microsoft Teams Rooms on Windows (MTR-W) only. Smart Gallery is available in Zoom Rooms only.
Simple One-Cable Setup
The A40 connects to your display and network with a straightforward setup, making installation clean and quick. When a laptop needs to run the meeting, simply switch to BYOD USB mode using a single cable.
Key Features
- For Small & Medium Rooms — Typically supports 6–11 participants.
- Dual 48MP Cameras — Auto Framing, Speaker Tracking, IntelliFocus.
- Smart Gallery — Zoom Rooms only.
- CTP25 Touch Panel Included — One-touch join & in-room meeting control.
- Native Teams Rooms & Zoom Rooms — Plus BYOD USB & SIP/H.323 modes.
- Expandable Audio — Supports up to two expansion microphones.
- MDEP-Aligned — Secure deployment & centralized device management.
Datasheet & Full Specifications
For complete technical details, see the Yealink MeetingBar A40 Datasheet (PDF).
You may also download the Yealink CTP25 Touch Panel Datasheet (PDF).
Prefer handheld remote control instead of a touch panel? View A40-010 bundle with VCR11 →
Package Contents (A40-031 Open Box)
- MeetingBar A40 Collaboration Bar
- CTP25 Touch Panel
- HDMI Cable × 2
- Network Cable × 1
- TV-Clip Mount × 1
- Wall Mount × 1
- Power Supply & Cables
- Quick Start / Manuals
Detailed Specifications
| Parameter | Description |
|---|---|
| Operating System | • Android 13 |
| Camera | • Maximum pixels: 2*48MP pixels • Number of preset positions: 9 • Electronic gimbal • 120° DFOV, 54° VFOV, 110° HFOV • Depth of field: 1-5 meters • 6x digital zoom • Maximum resolution: 4K • Maximum frame rate: 60FPS • Video output resolution: 4K60fps, 1080P60fps • Effective focal length: 4.2 mm • Aperture: F/2.2-F/2.4 • Supports wide dynamic range • High dynamic range imaging: 10-bit • Supports auto exposure • White balance: ATW/auto/manual • Shutter speed: 10ms-33ms • Minimum illumination: 0.5 lux (daytime), 0.1 lux (nighttime) • Signal-to-noise ratio: >63 dB • Privacy cover: Electric lens cap • Lens calibration • Intelligence Features - IntelliFocus - Auto Framing - Speaker Tracking People counting - Picture in Picture - Multi-focus Framing - Smart Gallery (Zoom only) • Number of cameras: 2 |
| Speaker | • Built-in 2 x 10W speakers • Maximum sound pressure level: 112dBSPL 10W@0.1m • Frequency response: 100-16kHz • Sensitivity: 86dB SPL @ 1W @ 0.5 meter • Sampling rate: 48kHz • Sound emission angle: Forward-facing • Total Harmonic Distortion (THD): at 10W, 1kHz, ＜5% • Rated impedance: 4 ohms • Maximum power: 12W • Rated power: 10W |
| Microphone | • Built-in 8 MEMS microphone array • 6-meter pickup distance, 4-meter high-quality pickup distance • Signal-to-noise ratio: 72dB • Maximum sound pressure level: 130dBSPL (whole device), 100dBSPL (individual microphone) • Dynamic range: 28-100dBSPL • Sensitivity: -38dBV/pa • Frequency response: 100-20kHz • Sampling rate: 48K32bit • Bit depth: 32-bit |
| Resolution | • Portrait resolution: up to 4K30fps • Bandwidth requirement: 10Mbps or more |
| Content sharing | • Up to 4K15 in General Mode • Teams: 1080p in meeting, 4K local sharing • Zoom: 1080p |
| Communication standard protocol | • SIP/H.323 in General Mode |
| Network Protocol | • Wi-Fi 6 - 2.4G & 5G dual-band, 802.11a/b/g/n/ac/ax - 2x2 MIMO • Bluetooth 5.0 • TCP/IP (IPv4/IPv6), DHCP/static IP • HTTPS secure web access |
| Configuration Management | • Automatic configuration via web page/display/AutoP • Firmware upgrade, factory reset • Configuration import and export • System log export |
| Device Management | • Yealink Https Web Portal • Yealink Device Management Platform • Yealink Management Cloud Service • Microsoft Device Management Platform(Microsoft Teams Admin Center/Intune) • Zoom Device Management |
| Installation | • Wall mount • Use TV-Clip Mount • Place on the desktop |
| Ports | • 1x USB2.0 USB-A port • 1x USB-C port • 1x Ethernet port • 1x Yealink VCH port (RJ-45) • 1x 3.5mm Line-in & Line-out port • 1x Power port • 1x Security lock slot • 1x Reset slot • 2x HDMI-out |
| Environmental Factor | • Operating humidity: 10 - 95% • Operating temperature: 0 - 40°C |
| Dimensions and weight (W × D × H) | • MeetingBar A40: 650 × 62 × 80 mm • N.W/CTN: 5.540 kg • G.W/CTN: 6.086kg |
MeetingBar A40 w/CTP25 Package Contents:
- MeetingBar A40
- HDMI cable x2
- Network cable x1
- TV-Clip Mount x1
- Wall Mount x1
- CTP25 Touch Panel
Frequently Asked Questions
What is included with the Yealink MeetingBar A40 with CTP25?
This bundle includes the Yealink MeetingBar A40 all-in-one video conferencing bar and the CTP25 touch panel. Additionally, it includes a TV-Clip Mount, Wall Mount, 2x HDMI cables, and 1x Network cable
What room size is the A40 designed for?
The MeetingBar A40 is ideal for medium-sized conference rooms. It provides wide-angle coverage and intelligent tracking to support hybrid meetings and collaborative sessions. Additionally, the microphone has a 6-meter pickup distance, 4-meter high-quality pickup distance.
What does the CTP25 touch panel do?
The CTP25 allows users to start meetings and control the video conference experience. It simplifies the user experience by acting as the central control unit for your meeting space.
Is the A40 compatible with both Microsoft Teams and Zoom?
Yes. The Yealink A40 supports both Microsoft Teams Rooms (MTR)** and **Zoom Rooms platforms, depending on configuration. It runs on Android and is optimized for easy deployment.
Can the A40 system be expanded?
Yes, the A40 supports add-ons such as microphones (VCM35, VCM36-W, CM20), speakers (CS10), cameras (MTower), and touch panels (CTP25). This makes it highly adaptable for growing or changing meeting spaces.
Is the MeetingBar A40 easy to install?
Yes, it’s a plug-and-play solution that mounts easily under or above a display and connects via Ethernet or Wi-Fi. The system is designed to simplify IT deployment and reduce setup time.
