Now you can answer your door or gate from the safety of your telephone! The W-1000 (flush
mount) and W-2000A (surface mount) doorboxes are designed to be installed on the unused telephone line input of nearly any phone system. One or two doorboxes can also share an existing
residential phone line and provide door strike and CCTV camera control when used in combination with a C-1000B doorbox controller.

When the Call button is pressed, the doorbox generates a standard ring cadence for an adjustable number of rings. To converse with the visitor, the inside party simply answers the call from the phone of their choice.

For outdoor or harsh environments, the W-1000 and W-2000A are available with Enhanced Weather Protection (EWP). The W-1000-EWP and W-2000A-EWP feature rubber gaskets and boots, closed cell foam gasketing, hand soldered silicon sealed connections, anti-corrosive gel filled butt connectors, as well as urethane encapsulated circuit boards with internally sealed, field-adjustable trim POTS and DIP switches

Applications

Residential and Business door security
Gate communication
Communication with truck stop/gas station fuel island
Communication with delivery and employee entrances
Use with Viking's C-1000B, RC-2A, or RC-3 to operate electronic door strikes
Add the VE-5x5 to allow the W-1000 to be surface mounted or attached to a gooseneck

Features

New high output speaker amplifier with volume adjustment POT
Microphone volume adjustment POT
24 volt talk battery
20 Hz ring generator (3.0 REN ring load maximum)
Selectable number of rings (2, 3, 10 or 30)
Extended operating temperature range: -15F to 130F
Compact 45 terminal strip for easy wiring
Optional Enhanced
Weather Protection
One year warranty
Made in the USA

Specifications

Power: 120V AC/13.8V AC 1.25A UL listed adapter provided
Dimensions: W-1000 - Overall - 127 x 127 x 57 mm (5.0 x 5.0
x 2.25), Plastic Electrical Box - 102 x 102 x 57mm (4 x 4 x
2.25), W-2000A - 140 x 115 x 38mm (5.5 x 4.5 x 1.5)
Shipping Weight: W-1000 - 1.36 kg (3 lbs), W-2000A - .75 kg
(1.5 lbs)
Standard W-1000/W-2000A Environment: -26 C to 54 C (-15
F to 130 F) with 5% to 95% non-condensing humidity
W-1000-EWP/W-2000A-EWP Environment: -26 C to 54 C (-
15 F to 130 F) with up to 100% condensing humidity
Ringer Output: 3.0 REN maximum, 20Hz
Ring Cadence: 1 second ON, 3 seconds OFF
Maximum Loop Length: 1.9 Km (6300 ft) - 24 AWG twisted pair
Maximum Power Run: 45.7 m (150 ft) - 24 AWG twisted pair
Speaker Volume: Approximately 70db maximum @ 1m
Standard Connections: (1) 4-position terminal block
EWP Connections: (4) gel-filled butt connectors
