The SLP-4 Single Line Paging Controller will allow you to page family members or co-workers from any phone in your home or small office. The pages can be heard over the same speakers that are installed for multi-zone music distribution.

The SLP-4 provides inputs for 4 lighted doorbell switches. The inputs select 4 different CD quality sounds from a library of eight factory recordings including Westminster bells, chimes, alert tones, barking dog, etc. Alternatively, users may record their own CD quality sounds into the SLP-4 from their PC’s USB port. When the doorbell switch is pressed, background music is muted while the appropriate sound is heard over the system speakers.

The SLP-4 connects in series with a single existing phone line. The unit has a built-in 2 watt amplifier, pre-amp output, music on hold input, intercom features, and selectable loud ringing.

CLICK HERE to preview factory sounds and download different sounds for the SLP-4

Applications

Whole house/small business paging from existing phones
Add paging, intercom, and music on hold features for small businesses
Loud ringing / night bell
Compatible with C-200, C-1000B and C-2000A
Museum or information display, 4 button audio server

Features

Stereo line level pre-amp inputs/outputs for whole house audio systems
Built-in two-watt mono paging amplifier with gain control
Phone to phone intercom
Place callers on music-on-hold when paging
Can provide background music from an external source
Background music mute (automatic during paging or touch tone selectable while you are on a call)
Selectable loud ringing (electronic warble over speakers)
Four doorbell switch inputs (lighted or non-lighted) for activating door chimes
USB port for loading custom wave file chime tones/ sounds/music
Nearly 6 minutes of recorded audio storage
Switch selectable on-hold alarm tones
Simple control commands - no touch tone programming
Page trigger output (12V signal for enabling paging source input on multi-source amps)
Individual Chime, Page, and Ringing volume controls
Bypass code - ignores all touch tones on next off-hook allowing you to steer through auto attendants, etc.
Page from multiple phone lines by connecting multiple units
Comes complete with power supply

Specifications

Power: 120V AC/13.8V AC 1.25A, UL listed adapter provided
Dimensions: 210mm x 159mm x 45mm (8.25” x 6.25” x 1.75”)
Shipping Weight: 1.5 kg (3.2 lbs)
Environmental: 0°C to 32°C (32°F to 90°F) with 5% to 95% non-condensing humidity
Paging Amplifier Output: 2 watts - powers up to (3) 8 ohm (16) 45 ohm speakers
Sound Pressure: 100 dB @ 1 meter (loud electronic warble from 25AE paging horn)
REN: 0.5A
Maximum Speaker Output Wire Run: 91m (300 ft), 18 AWG
Maximum Doorbell Switch Wire Run: 305m (1000 ft), 24 AWG
Maximum Load on Page Trigger Output: 1K Ohm
Talk Battery: 36V DC
Connections: 24 screw terminal block positions, (4) RCA jacks, (1) Type B USB jack, (1) 3.5mm (1/8”) audio jack
