Viking Electronics IP Paging Speaker Adapter w/Talk-Back (PSA-TB-IP)

The Viking model PSA-TB-IP Paging Speaker Adapter with Talk-Back enables you to quickly convert any 8 ohm, 25V or 70V analog paging speaker into a SIP endpoint paging speaker. The microphone enables Talk-Back and also monitors room noise to automatically increase the speaker volume when necessary. After the quick conversion the speaker can then be used for standard one-way SIP endpoint paging, two-way conversations via SIP endpoint paging, one-way multicast paging and making standard or emergency two-way SIP calls initiated from its switch input.

The PSA-TB-IP’s compact chassis is easily attached magnetically to the back of the speaker magnet or fastened to the 25/70V transformer mounting holes on the speaker frame. Use the provided connectors to simply attach to the existing speaker wires then connect with a single CAT5/6 cable from your PoE switch.

An optional auxiliary switch input allows a hard wired wall button, concealed under desk switch, etc. to initiate a SIP call. A momentary button press will initiate a standard call, while holding the button for 3 or more seconds will initiate an emergency call.

The PSA-TB-IP has a high efficiency 6 watt class D amplifier capable of driving up to six 8 Ohm analog paging speakers. This allows you to use a single PSA-TB-IP to cover up to a six speaker paging zone with approximately one watt of paging power per speaker.

Viking PSA-TB-IP Adapter Features

SIP compliant (see page two for compatible SIP servers and IP phone systems)
PoE powered (class 3, <13 Watts)
Paging prioritization
Plays audio from standard multicast sources
SIP endpoint or multicast group member
Red call status LED indicator
Automatic Noise Canceling (ANC) feature for operation in noisy environments
Viking’s proprietary VOX switching eliminates the need for “Push to Talk” mode
Selectable auto-answer feature for monitoring
Compatible with Polycom multicast paging
Built-in high efficiency 6 Watt class D amplifier
Can drive up to six 8 ohm analog speakers for greater coverage
SIP/Multicast: SIP page, SIP page and zoned multicast receive
Support for access code to prevent unwanted SIP calls
Hangs up on: busy signal, time-out, or touch tone command
Network remote speaker volume control
Mounting: Magnetically attach to speaker magnet or fasten to the 25/70V transformer
mounting holes on speaker frame
Chassis protects circuitry against plenum dust
Automatic Gain Control (AGC) to automatically increase ring volume to compensate for
ambient noise
Diagnostics for testing microphone and speaker
Programmable pre-page alert tone
